Router un ticket de support vers la bonne équipe
Envoyer chaque ticket de support entrant à l'équipe capable d'y répondre.
RecommandéN1 Révisée le
| Barreau | Approche | Coût | Latence | Données | Déterministe | Verdict |
|---|---|---|---|---|---|---|
| N0 — Règle et algorithme classique | Règles par mots-clés, avec priorité explicite et file par défaut | Nul | <1 ms | Rien ne sort | Oui | |
| N1 — Modèle classique léger | TF-IDF et classifieur linéaire entraîné sur l'archive | Négligeable | ~10 ms | Reste dans votre infrastructure | Oui | Recommandé |
| N2 — Petit modèle spécialisé auto-hébergé | Encodeur de phrases auto-hébergé, vote des tickets résolus voisins | Faible | ~100 ms | Reste dans votre infrastructure | Oui | |
| N3 — API de LLM généraliste | Classement par appel à un modèle généraliste, contre une liste fermée d'équipes | Élevé | ~1 s | Part chez un tiers | Non |
N0 — Règle et algorithme classique Règle et algorithme classique
Règles par mots-clés, avec priorité explicite et file par défaut
- Coût
- Nul
- Latence
<1 ms
Preuve d’exécution : Code exécuté tel quel
Cet extrait s’exécute avec ses vraies dépendances, et son test tourne à chaque construction du site.
Python
"""
Route a support ticket with keyword rules: ordered, with a default team.
Rung N0. Deterministic, standard library only, and every decision can be
explained to the person who asks why their ticket landed where it did.
Two things turn a keyword list into a rule a support desk can actually run.
First, an explicit priority. Tickets mention several subjects, so two teams
matching the same ticket is the normal case, not the exception. The order of
RULES answers it once and in writing, rather than leaving it to whichever
branch happens to run first.
Second, a default team. Every ticket must land somewhere; a ticket that
matches nothing has to go to a queue a human watches, not to the floor.
"""
import re
import unicodedata
# The queue that gets everything the rules cannot place. Naming it here, next
# to the rules, is what stops a ticket from silently going nowhere.
DEFAULT_TEAM = "general"
# Business knowledge, kept next to the code that applies it.
#
# The order is the priority, and it is a business decision, not a detail of
# implementation: a billing problem has a legal clock on it, an outage blocks
# the customer's work, a parcel is the one that can wait a day. Whoever
# disagrees can reorder this tuple and nothing else.
RULES = (
("billing", ("facture", "remboursement", "prélèvement", "iban", "devis", "paiement")),
("technical", ("bug", "erreur", "panne", "connexion", "mot de passe", "identifiant")),
("shipping", ("livraison", "colis", "transporteur", "expédition", "suivi", "retard")),
)
def _fold(text: str) -> str:
"""Lowercase and drop accents, so « Prélèvement » matches « prelevement »."""
decomposed = unicodedata.normalize("NFD", text.lower())
return "".join(c for c in decomposed if not unicodedata.combining(c))
# A word boundary on the left only. « facture » then also matches « factures »
# and « facturation », which is what French tickets are full of; the price is
# that it would match a longer word starting the same way.
_COMPILED = tuple(
(team, tuple((word, re.compile(rf"\b{re.escape(_fold(word))}")) for word in words))
for team, words in RULES
)
def matches(ticket: str) -> dict[str, list[str]]:
"""
Every team the ticket triggers, with the words that triggered it.
The routing decision needs only the first team, but the reviewer of a
misrouted ticket needs this: it shows what the rules saw, and what they
had to drop.
"""
folded = _fold(ticket)
found = {}
for team, patterns in _COMPILED:
hits = [word for word, pattern in patterns if pattern.search(folded)]
if hits:
found[team] = hits
return found
def route(ticket: str, default_team: str = DEFAULT_TEAM) -> str:
"""The team that gets the ticket. Always one, and always a real queue."""
found = matches(ticket)
for team, _ in RULES:
if team in found:
return team
return default_teamJavaScript
/**
* Route a support ticket with keyword rules: ordered, with a default team.
*
* Rung N0. Deterministic, no dependency, and every decision can be explained
* to the person who asks why their ticket landed where it did.
*
* Two things turn a keyword list into a rule a support desk can actually run.
*
* First, an explicit priority. Tickets mention several subjects, so two teams
* matching the same ticket is the normal case, not the exception. The order of
* RULES answers it once and in writing, rather than leaving it to whichever
* branch happens to run first.
*
* Second, a default team. Every ticket must land somewhere; a ticket that
* matches nothing has to go to a queue a human watches, not to the floor.
*/
// The queue that gets everything the rules cannot place. Naming it here, next
// to the rules, is what stops a ticket from silently going nowhere.
export const DEFAULT_TEAM = 'general';
/**
* Business knowledge, kept next to the code that applies it.
*
* The order is the priority, and it is a business decision, not a detail of
* implementation: a billing problem has a legal clock on it, an outage blocks
* the customer's work, a parcel is the one that can wait a day. Whoever
* disagrees can reorder this list and nothing else.
*/
export const RULES = [
['billing', ['facture', 'remboursement', 'prélèvement', 'iban', 'devis', 'paiement']],
['technical', ['bug', 'erreur', 'panne', 'connexion', 'mot de passe', 'identifiant']],
['shipping', ['livraison', 'colis', 'transporteur', 'expédition', 'suivi', 'retard']],
];
/** Lowercase and drop accents, so « Prélèvement » matches « prelevement ». */
function fold(text) {
return text.toLowerCase().normalize('NFD').replace(/\p{M}/gu, '');
}
// A word boundary on the left only. « facture » then also matches « factures »
// and « facturation », which is what French tickets are full of; the price is
// that it would match a longer word starting the same way.
const COMPILED = RULES.map(([team, words]) => [
team,
words.map((word) => [word, new RegExp(`\\b${fold(word).replace(/[.*+?^${}()|[\]\\]/g, '\\$&')}`)]),
]);
/**
* Every team the ticket triggers, with the words that triggered it.
*
* The routing decision needs only the first team, but the reviewer of a
* misrouted ticket needs this: it shows what the rules saw, and what they had
* to drop.
*/
export function matches(ticket) {
const folded = fold(ticket);
const found = {};
for (const [team, patterns] of COMPILED) {
const hits = patterns.filter(([, pattern]) => pattern.test(folded)).map(([word]) => word);
if (hits.length) found[team] = hits;
}
return found;
}
/** The team that gets the ticket. Always one, and always a real queue. */
export function route(ticket, defaultTeam = DEFAULT_TEAM) {
const found = matches(ticket);
for (const [team] of RULES) {
if (team in found) return team;
}
return defaultTeam;
}Risques
- Sortie de données
- Rien ne sort
- Déterminisme
- Oui
- Testabilité
- Testable unitairement
- Dépendance fournisseur
- Aucune
- Empreinte
- Négligeable
- Périmètre réglementaire
-
- Aucun périmètre spécifique ajouté : le ticket est traité là où il est déjà stocké
Point de rupture
Le ticket qui appartient à deux équipes, et celui qui n'en déclenche aucune. « Le colis n'est jamais arrivé et le prélèvement est passé quand même » déclenche facturation et livraison ; la priorité tranche pour facturation, et la moitié colis disparaît sans trace dans la file qui reçoit le ticket. À l'autre bout, « je n'arrive plus à faire ce que je faisais avant » ne déclenche rien et part dans la file par défaut.
Quand monter d’un barreau
La file par défaut devient la file la plus remplie.
N1 — Modèle classique léger Modèle classique léger Recommandé
TF-IDF et classifieur linéaire entraîné sur l'archive
- Coût
- Négligeable
- Latence
~10 ms
Preuve d’exécution : Code exécuté tel quel
Cet extrait s’exécute avec ses vraies dépendances, et son test tourne à chaque construction du site.
Python
"""
Route a ticket with TF-IDF and a linear classifier trained on the archive.
Rung N1. The keyword rules of N0 know the words someone thought of. This
knows the words the desk actually received: it is trained on the tickets the
teams have already answered, so the vocabulary of the customers, not the
vocabulary of the rule writer, decides.
What it keeps from N0, deliberately: a default team. A classifier always
returns something, and its most likely class on a ticket it has no opinion
about is still a class. The confidence floor below is what turns that shrug
back into the default queue, instead of a wrong queue.
Training data is the exported archive: the resolved tickets and the team that
resolved each one. The model is a table of weights small enough to keep in the
repository, and retraining it is a step in the nightly export, not a project.
"""
from sklearn.feature_extraction.text import TfidfVectorizer
from sklearn.linear_model import LogisticRegression
from sklearn.pipeline import make_pipeline
DEFAULT_TEAM = "general"
def train(tickets: list[str], teams: list[str]):
"""
`teams` is the team that actually handled each past ticket.
Word pairs as well as single words, because « mot de passe » and « en
retard » carry more than the words they are made of. Classes are weighted
by their rarity: an archive is never balanced, and an unweighted model
learns to answer the busiest team.
"""
model = make_pipeline(
TfidfVectorizer(strip_accents="unicode", ngram_range=(1, 2), sublinear_tf=True),
# C loosens the penalty: the default is set for documents, and on texts
# as short as a ticket it flattens the probabilities so far that no
# ticket ever clears a useful floor.
LogisticRegression(class_weight="balanced", max_iter=1000, C=10),
)
model.fit(tickets, teams)
return model
def rank(model, ticket: str) -> list[tuple[str, float]]:
"""
Every team with the probability the model gives it, best first.
A support desk needs the runner-up: two teams at almost the same score is
exactly the ambiguous ticket of N0, and here it is visible instead of
being silently resolved by a priority order.
"""
probabilities = model.predict_proba([ticket])[0]
ranked = sorted(zip(model.classes_, probabilities), key=lambda pair: -pair[1])
return [(str(team), float(probability)) for team, probability in ranked]
def route(model, ticket: str, min_confidence: float = 0.5,
default_team: str = DEFAULT_TEAM) -> str:
"""
The team that gets the ticket, or the default queue below the floor.
The floor is yours to set. Raise it and more tickets are read by a human
before they move; lower it and more tickets are moved on a hunch. Nothing
in the model can make that choice for you.
"""
team, confidence = rank(model, ticket)[0]
return team if confidence >= min_confidence else default_teamJavaScript
/**
* Route a ticket with TF-IDF and a linear classifier trained on the archive.
*
* Rung N1. The keyword rules of N0 know the words someone thought of. This
* knows the words the desk actually received: it is trained on the tickets the
* teams have already answered, so the vocabulary of the customers, not the
* vocabulary of the rule writer, decides.
*
* Written out rather than pulled from a library, because TF-IDF and a softmax
* regression are forty lines. The model is a table of weights: small enough to
* keep beside the code, retrained while you read this, and every weight can be
* printed and argued about when someone asks why their ticket moved.
*
* What it keeps from N0, deliberately: a default team. A classifier always
* returns something, and its most likely class on a ticket it has no opinion
* about is still a class. The confidence floor is what turns that shrug back
* into the default queue, instead of a wrong queue.
*/
export const DEFAULT_TEAM = 'general';
/** Words of a ticket, lowercased and stripped of accents. */
function tokens(text) {
const folded = text.toLowerCase().normalize('NFD').replace(/\p{M}/gu, '');
const words = folded.match(/[\p{L}\p{N}]+/gu) ?? [];
// Word pairs as well as single words, because « mot de passe » and « en
// retard » carry more than the words they are made of.
return words.concat(words.slice(0, -1).map((w, i) => `${w} ${words[i + 1]}`));
}
/** Vocabulary and inverse document frequency, learnt from the archive alone. */
function fitVocabulary(tickets) {
const seen = new Map();
for (const ticket of tickets) {
for (const term of new Set(tokens(ticket))) seen.set(term, (seen.get(term) ?? 0) + 1);
}
const terms = new Map();
const idf = [];
for (const [term, documents] of seen) {
terms.set(term, idf.length);
idf.push(Math.log((1 + tickets.length) / (1 + documents)) + 1);
}
return { terms, idf };
}
/** One TF-IDF row, brought to length one. Unknown terms are simply dropped. */
function vector(vocabulary, ticket) {
const counts = new Map();
for (const term of tokens(ticket)) {
const j = vocabulary.terms.get(term);
if (j !== undefined) counts.set(j, (counts.get(j) ?? 0) + 1);
}
const row = new Float64Array(vocabulary.idf.length);
// Sublinear term frequency: a word repeated ten times is not ten times the
// signal, and an angry customer repeats words.
for (const [j, count] of counts) row[j] = (1 + Math.log(count)) * vocabulary.idf[j];
const norm = Math.hypot(...row);
if (norm) for (const [j] of counts) row[j] /= norm;
return row;
}
/** Softmax over the teams: one score per team, summing to one. */
function scores(model, row) {
const raw = model.classes.map((_, c) => {
let z = model.bias[c];
for (let j = 0; j < row.length; j += 1) z += model.weights[c][j] * row[j];
return z;
});
const top = Math.max(...raw);
const exponentials = raw.map((z) => Math.exp(z - top));
const total = exponentials.reduce((a, b) => a + b, 0);
return exponentials.map((e) => e / total);
}
/**
* `teams` is the team that actually handled each past ticket.
*
* Each example is weighted by the rarity of its team: an archive is never
* balanced, and an unweighted model learns to answer the busiest team.
*/
export function train(tickets, teams, { epochs = 300, rate = 1 } = {}) {
const vocabulary = fitVocabulary(tickets);
const classes = [...new Set(teams)].sort();
const rows = tickets.map((t) => vector(vocabulary, t));
const share = new Map(classes.map((c) => [c, teams.filter((t) => t === c).length]));
const model = {
vocabulary,
classes,
weights: classes.map(() => new Float64Array(vocabulary.idf.length)),
bias: new Float64Array(classes.length),
};
for (let epoch = 0; epoch < epochs; epoch += 1) {
for (let i = 0; i < rows.length; i += 1) {
const predicted = scores(model, rows[i]);
const step = (rate * teams.length) / (classes.length * share.get(teams[i]));
for (let c = 0; c < classes.length; c += 1) {
const error = predicted[c] - (teams[i] === classes[c] ? 1 : 0);
for (let j = 0; j < rows[i].length; j += 1) model.weights[c][j] -= step * error * rows[i][j];
model.bias[c] -= step * error;
}
}
}
return model;
}
/**
* Every team with the probability the model gives it, best first.
*
* A support desk needs the runner-up: two teams at almost the same score is
* exactly the ambiguous ticket of N0, and here it is visible instead of being
* silently resolved by a priority order.
*/
export function rank(model, ticket) {
const probabilities = scores(model, vector(model.vocabulary, ticket));
return model.classes
.map((team, c) => [team, probabilities[c]])
.sort((a, b) => b[1] - a[1]);
}
/**
* The team that gets the ticket, or the default queue below the floor.
*
* The floor is yours to set. Raise it and more tickets are read by a human
* before they move; lower it and more tickets are moved on a hunch. Nothing in
* the model can make that choice for you.
*/
export function route(model, ticket, { minConfidence = 0.5, defaultTeam = DEFAULT_TEAM } = {}) {
const [team, confidence] = rank(model, ticket)[0];
return confidence >= minConfidence ? team : defaultTeam;
}Risques
- Sortie de données
- Reste dans votre infrastructure
- Déterminisme
- Oui
- Testabilité
- Testable statistiquement
- Dépendance fournisseur
- Bibliothèque
- Empreinte
- Faible
- Périmètre réglementaire
-
- Constitution d'un corpus d'entraînement à partir de tickets clients réels, conservé à part des tickets dont il est tiré
- Le corpus entre dans votre registre des traitements si vous en tenez un
Point de rupture
Le modèle connaît l'archive, et rien d'autre. « Votre entrepôt accepte-t-il les visites scolaires le mercredi » ne recoupe aucun mot des tickets déjà résolus : les trois équipes ressortent presque à égalité, le seuil de confiance n'est pas atteint, et le ticket repart dans la file par défaut. N1 n'a pas supprimé cette file, il l'a rétrécie.
Quand monter d’un barreau
Vos agents ressortent régulièrement de la file par défaut des tickets qui se révèlent être des problèmes connus, décrits avec des mots absents de l'archive.
N2 — Petit modèle spécialisé auto-hébergé Petit modèle spécialisé auto-hébergé
Encodeur de phrases auto-hébergé, vote des tickets résolus voisins
- Coût
- Faible
- Latence
~100 ms
Preuve d’exécution : Code exécuté, service externe simulé
Cet extrait s’exécute à chaque construction du site, mais son test remplace le service externe par un double local. Ce qui est vérifié : la requête envoyée, la réponse décodée et les cas d’erreur. Ce qui ne l’est pas : la qualité de la réponse du modèle.
Python
"""
Route a ticket by its nearest resolved tickets, with a self-hosted encoder.
Rung N2. N1 learns the words of the archive; an encoder maps a ticket to a
vector by meaning, so a customer who says « je n'arrive plus à entrer dans mon
espace » lands next to the archived tickets about a lost password even though
they share no word with them.
There is no training step here, and that is the point of the rung: the index
is the archive itself. A team that changes scope is a re-encoding, not a
retraining, and the neighbours are shown to the agent as the reason for the
routing — which is more than N1's weights ever explain.
What it costs: a model file to ship and keep in sync, a warm process to hold
it, and a routing whose answers change the day you upgrade the model. The
archive also has to be re-encoded then, and the old scores are not comparable
to the new.
"""
from __future__ import annotations
MODEL_NAME = "sentence-transformers/paraphrase-multilingual-MiniLM-L12-v2"
DEFAULT_TEAM = "general"
def load_encoder(name: str = MODEL_NAME):
"""The real encoder: fetched once, then held in memory and run locally."""
from sentence_transformers import SentenceTransformer # pragma: no cover
return SentenceTransformer(name)
def build_index(tickets: list[str], teams: list[str], encoder=None) -> dict:
"""
Encode the resolved archive once, and keep the encoder for the queries.
`encoder` is injected so this can be tested without loading a model. Left
alone, it is the real one above.
"""
encoder = load_encoder() if encoder is None else encoder
tickets = list(tickets)
return {"tickets": tickets, "teams": list(teams), "encoder": encoder,
"vectors": [_unit(v) for v in encoder.encode(tickets)]}
def neighbours(index: dict, ticket: str, k: int = 3) -> list[tuple[float, str]]:
"""The k nearest resolved tickets, best first, with their cosine score."""
vector = _unit(index["encoder"].encode([ticket])[0])
scored = [(_dot(known, vector), team)
for known, team in zip(index["vectors"], index["teams"])]
# A stable sort, so two equally close tickets always come back in archive
# order. A routing run has to be replayable.
scored.sort(key=lambda pair: -pair[0])
return scored[:k]
def route(index: dict, ticket: str, k: int = 3, min_similarity: float = 0.25,
default_team: str = DEFAULT_TEAM) -> str:
"""
The team of the nearest resolved tickets, each voting with its similarity.
A vote rather than the single best neighbour: one archived ticket that
happens to be phrased like this one is an accident, three of them are a
pattern.
The floor is what keeps the default queue of N0 alive. Below it, nothing
in the archive resembles this ticket, and the honest answer is that this
rung has never seen the problem.
"""
votes: dict[str, float] = {}
for similarity, team in neighbours(index, ticket, k):
if similarity >= min_similarity:
votes[team] = votes.get(team, 0.0) + similarity
if not votes:
return default_team
# Ties go to the team of the closest neighbour, which is the first key
# inserted above.
return max(votes, key=lambda team: votes[team])
def _unit(vector) -> list[float]:
"""Cosine similarity is a dot product once both sides have length one."""
values = [float(v) for v in vector]
norm = sum(v * v for v in values) ** 0.5
return [v / norm for v in values] if norm else values
def _dot(a: list[float], b: list[float]) -> float:
return sum(x * y for x, y in zip(a, b))JavaScript
/**
* Route a ticket by its nearest resolved tickets, with a self-hosted encoder.
*
* Rung N2. N1 learns the words of the archive; an encoder maps a ticket to a
* vector by meaning, so a customer who says « je n'arrive plus à entrer dans
* mon espace » lands next to the archived tickets about a lost password even
* though they share no word with them.
*
* There is no training step here, and that is the point of the rung: the index
* is the archive itself. A team that changes scope is a re-encoding, not a
* retraining, and the neighbours are shown to the agent as the reason for the
* routing — which is more than N1's weights ever explain.
*
* What it costs: a model file to ship and keep in sync, a warm process to hold
* it, and a routing whose answers change the day you upgrade the model. The
* archive also has to be re-encoded then, and the old scores are not
* comparable to the new.
*/
export const MODEL_NAME = 'Xenova/paraphrase-multilingual-MiniLM-L12-v2';
export const DEFAULT_TEAM = 'general';
/** The real encoder: fetched once, then held in memory and run locally. */
export async function loadEncoder(name = MODEL_NAME) {
const { pipeline } = await import('@xenova/transformers');
const extract = await pipeline('feature-extraction', name);
return { encode: async (texts) => (await extract(texts, { pooling: 'mean' })).tolist() };
}
/**
* Encode the resolved archive once, and keep the encoder for the queries.
*
* `encoder` is injected so this can be tested without loading a model. Left
* alone, it is the real one above.
*/
export async function buildIndex(tickets, teams, encoder) {
const model = encoder ?? (await loadEncoder());
const kept = [...tickets];
return {
tickets: kept,
teams: [...teams],
encoder: model,
vectors: (await model.encode(kept)).map(unit),
};
}
/** The k nearest resolved tickets, best first, with their cosine score. */
export async function neighbours(index, ticket, k = 3) {
const vector = unit((await index.encoder.encode([ticket]))[0]);
const scored = index.vectors.map((known, i) => [dot(known, vector), index.teams[i]]);
// A stable sort, so two equally close tickets always come back in archive
// order. A routing run has to be replayable.
return scored.sort((a, b) => b[0] - a[0]).slice(0, k);
}
/**
* The team of the nearest resolved tickets, each voting with its similarity.
*
* A vote rather than the single best neighbour: one archived ticket that
* happens to be phrased like this one is an accident, three of them are a
* pattern.
*
* The floor is what keeps the default queue of N0 alive. Below it, nothing in
* the archive resembles this ticket, and the honest answer is that this rung
* has never seen the problem.
*/
export async function route(index, ticket, { k = 3, minSimilarity = 0.25, defaultTeam = DEFAULT_TEAM } = {}) {
const votes = new Map();
for (const [similarity, team] of await neighbours(index, ticket, k)) {
if (similarity >= minSimilarity) votes.set(team, (votes.get(team) ?? 0) + similarity);
}
if (votes.size === 0) return defaultTeam;
// Ties go to the team of the closest neighbour, which is the first key
// inserted above.
let best = defaultTeam;
let bestVote = -Infinity;
for (const [team, vote] of votes) {
if (vote > bestVote) [best, bestVote] = [team, vote];
}
return best;
}
/** Cosine similarity is a dot product once both sides have length one. */
function unit(vector) {
let sum = 0;
for (const v of vector) sum += v * v;
const norm = Math.sqrt(sum);
return norm ? vector.map((v) => v / norm) : [...vector];
}
function dot(a, b) {
let total = 0;
for (let i = 0; i < a.length; i += 1) total += a[i] * b[i];
return total;
}Risques
- Sortie de données
- Reste dans votre infrastructure
- Déterminisme
- Oui
- Testabilité
- Testable statistiquement
- Dépendance fournisseur
- Bibliothèque
- Empreinte
- Modérée
- Périmètre réglementaire
-
- Copie encodée de l'archive conservée comme index sur votre infrastructure
- Une demande d'effacement portant sur un ticket archivé porte aussi sur l'index, qui en est une copie
- Modèle téléchargé auprès d'un tiers : sa licence et sa provenance sont à vérifier
Point de rupture
Il n'y a pas de modèle des équipes ici, seulement une archive, et le ticket le plus proche n'est pas toujours un ticket pertinent. « Bonjour, merci de me confirmer que vous avez bien reçu mon dossier » ne s'adresse à personne en particulier, et part chez facturation avec un score élevé : l'archive contient un ticket de facturation écrit avec les mêmes formules de politesse, et le vote y voit une forte ressemblance. Un vrai encodeur déplace l'accident, il ne le supprime pas : ce dont l'archive est faite est la politique de routage, y compris ce que personne n'y a choisi.
Quand monter d’un barreau
Des tickets arrivent dans une langue absente de l'archive, ou la règle de routage existe sous forme de consigne écrite qu'aucun ticket résolu n'illustre.
N3 — API de LLM généraliste API de LLM généraliste
Classement par appel à un modèle généraliste, contre une liste fermée d'équipes
- Coût
- Élevé
- Latence
~1 s
Preuve d’exécution : Code exécuté, service externe simulé
Cet extrait s’exécute à chaque construction du site, mais son test remplace le service externe par un double local. Ce qui est vérifié : la requête envoyée, la réponse décodée et les cas d’erreur. Ce qui ne l’est pas : la qualité de la réponse du modèle.
Python
"""
Route a ticket by asking a general-purpose model.
Rung N3. This is the option people reach for first, and it is the shortest
piece of routing logic on the entry: no rules to maintain, no archive to
label, and a ticket in any language.
Note what the code has to do that N0 did not: cap the input size, retry a
provider that fails, parse an answer that is only probably JSON, and refuse a
team the model made up. That plumbing is the real cost of this rung, and it is
the part your tests have to cover, because the model itself is not testable.
Read the end of `route` closely. A model answers with words, and
words are not queues. The closed list is the only thing standing between a
confident answer and a ticket sitting in a queue nobody watches.
"""
from __future__ import annotations
import json
# The queues that exist. Business knowledge, and here also a safety rail.
TEAMS = ("billing", "technical", "shipping")
DEFAULT_TEAM = "general"
MAX_CHARACTERS = 4000
PROMPT = (
"You are routing a customer support ticket to one team.\n"
"Answer with JSON only: {{\"team\": \"...\"}} where team is one of: {teams}.\n"
"If the ticket does not clearly belong to one of them, answer {default!r}.\n\n"
"Ticket:\n{ticket}"
)
class RoutingUnavailable(Exception):
"""The provider could not be reached, or answered something unparseable."""
def route(ticket: str, client=None, *, attempts: int = 3) -> str:
"""
The team that gets the ticket.
`client` is injected so this function can be tested without a network
call. In production it defaults to a real provider client.
"""
if client is None: # pragma: no cover - needs a key and a network
from openai import OpenAI
client = OpenAI()
# A model charges by the token, and a ticket with a forwarded thread under
# it is long. Refusing oversized input is not an optimisation, it is a
# cost control.
if len(ticket) > MAX_CHARACTERS:
raise ValueError(f"ticket longer than {MAX_CHARACTERS} characters")
answer = _ask(client, ticket, attempts)
team = answer.get("team") if isinstance(answer, dict) else None
team = str(team).strip().lower() if team is not None else ""
# Two failures, two treatments. A provider that cannot answer is an
# incident, and `_ask` above raises. A model that answers a team nobody
# created is a normal Tuesday, and the ticket goes to the default queue.
return team if team in TEAMS else DEFAULT_TEAM
def _ask(client, ticket: str, attempts: int) -> dict:
prompt = PROMPT.format(teams=", ".join(TEAMS), default=DEFAULT_TEAM, ticket=ticket)
last_error: Exception | None = None
for _ in range(attempts):
try:
# Temperature zero, because a routing decision that changes
# between two identical calls cannot be reviewed.
return json.loads(client.complete(prompt=prompt, temperature=0))
except Exception as error: # noqa: BLE001 - any provider failure is retried
last_error = error
raise RoutingUnavailable(str(last_error))JavaScript
/**
* Route a ticket by asking a general-purpose model.
*
* Rung N3. This is the option people reach for first, and it is the shortest
* piece of routing logic on the entry: no rules to maintain, no archive to
* label, and a ticket in any language.
*
* Note what the code has to do that N0 did not: cap the input size, retry a
* provider that fails, parse an answer that is only probably JSON, and refuse
* a team the model made up. That plumbing is the real cost of this rung, and
* it is the part your tests have to cover, because the model itself is not
* testable.
*
* Read the end of `route` closely. A model answers with words, and words are
* not queues. The closed list is the only thing standing between a confident
* answer and a ticket sitting in a queue nobody watches.
*/
// The queues that exist. Business knowledge, and here also a safety rail.
export const TEAMS = ['billing', 'technical', 'shipping'];
export const DEFAULT_TEAM = 'general';
export const MAX_CHARACTERS = 4000;
const PROMPT = [
'You are routing a customer support ticket to one team.',
`Answer with JSON only: {"team": "..."} where team is one of: ${TEAMS.join(', ')}.`,
`If the ticket does not clearly belong to one of them, answer '${DEFAULT_TEAM}'.`,
'',
'Ticket:',
].join('\n');
export class RoutingUnavailable extends Error {}
/**
* The team that gets the ticket.
*
* @param {string} ticket
* @param {object} options
* @param {{complete: Function}} [options.client] injected so this can be
* tested without a network call; defaults to a real provider client
* @param {number} [options.attempts]
*/
export async function route(ticket, { client, attempts = 3 } = {}) {
if (!client) {
// Needs a key and a network, so it is never reached in the tests.
const { OpenAI } = await import('openai');
client = new OpenAI();
}
// A model charges by the token, and a ticket with a forwarded thread under
// it is long. Refusing oversized input is not an optimisation, it is a cost
// control.
if (ticket.length > MAX_CHARACTERS) {
throw new RangeError(`ticket longer than ${MAX_CHARACTERS} characters`);
}
const answer = await ask(client, ticket, attempts);
const named = answer && typeof answer.team === 'string' ? answer.team.trim().toLowerCase() : '';
// Two failures, two treatments. A provider that cannot answer is an
// incident, and `ask` above throws. A model that answers a team nobody
// created is a normal Tuesday, and the ticket goes to the default queue.
return TEAMS.includes(named) ? named : DEFAULT_TEAM;
}
async function ask(client, ticket, attempts) {
let lastError;
for (let i = 0; i < attempts; i += 1) {
try {
// Temperature zero, because a routing decision that changes between two
// identical calls cannot be reviewed.
const answer = await client.complete({ prompt: `${PROMPT}\n${ticket}`, temperature: 0 });
return JSON.parse(answer);
} catch (error) {
lastError = error;
}
}
throw new RoutingUnavailable(String(lastError));
}Risques
- Sortie de données
- Part chez un tiers
- Déterminisme
- Non
- Testabilité
- Difficilement testable
- Dépendance fournisseur
- Fournisseur externe
- Empreinte
- Élevée
- Périmètre réglementaire
-
- Transfert du contenu des tickets à un sous-traitant, avec l'encadrement contractuel que cela suppose
- Un ticket est du texte libre : le transfert porte aussi sur ce que le client y a écrit sans qu'on le lui demande
- Localisation du traitement à vérifier auprès du fournisseur
- Ne vous dispense pas de vos propres obligations d'information et de minimisation
Point de rupture
Le modèle répond des mots, et les mots ne sont pas des files. Interrogé sur trois équipes, il en renvoie une quatrième qui sonne juste et n'existe pas : « customer success », en JSON parfaitement formé, sans la moindre hésitation. La liste fermée l'attrape et le ticket part dans la file par défaut ; retirez ce contrôle, comme le fait la première version de ce genre de code, et le ticket est classé dans une équipe que personne n'a créée et que personne ne surveille.
Quand monter d’un barreau
Il n'y a pas de barreau au-dessus.
Le verdict
RecommandéN1
N1 l'emporte parce que ses données d'entraînement existent déjà : l'archive des tickets résolus, chacun étiqueté par l'équipe qui l'a fermé, est à un export de distance, et elle route les formulations que la liste de mots-clés de N0 n'avait pas prévues. Elle remet aussi le ticket ambigu sur la table, puisque l'équipe suivante figure dans la réponse, là où N0 la laissait tomber sans le dire. N2 achète la reconnaissance des paraphrases au prix d'un fichier de modèle, d'un processus chaud et d'un index à ré-encoder à chaque mise à jour : ce prix se paie le jour où vos agents repêchent des problèmes connus dans la file par défaut, pas avant.
Pour aller plus loin
- scikit-learn — Extraction de caractéristiques sur du texte, TF-IDF
- scikit-learn — Classification de documents texte, exemple complet
- Introduction to Information Retrieval — la pondération tf-idf
- Sentence Transformers — encodeurs de phrases auto-hébergés
