Extract the tables from a PDF

"""
Read the tables of a PDF, and say how they were read.

Rung N0. A table in a PDF is not a table: it is text placed at coordinates,
sometimes with lines drawn around it. Two readings follow from that, and they
are not equally trustworthy.

When the table is ruled, the lines say where the cells are, and reading it is
exact. `pdfplumber` does that here, and it is the one thing this entry does not
write itself: finding the rules, pairing them into a grid and assigning the
words to cells is its job, and it does it well.

When there is no rule, the columns have to be guessed from where the words sit.
That guess is written below, in both languages, so that the two answer the same
thing — there is no equivalent of `pdfplumber` in JavaScript, and its own
fallback cuts a cell wider than its column, turning « Prix HT » into « Prix H ».

Which reading was used is in the report, because the caller should not have to
wonder: `strategy` is « lines » when the page said where the cells were, and
« text » when the code decided. Only Python can answer « lines »: there is no
JavaScript package that reads the rules of a PDF, so that side always guesses.

The guess is made from the whole page, not from the table: the columns come
from every left edge seen on the page, address block and footer included. That
is why a guessed reading keeps only the lines with at least two filled cells —
« SARL Le Moulin » alone on its line is the letterhead, not a row. What it left
out is not thrown away: `dropped_lines` holds the text of every line it
refused, so nothing read on the page is lost, and what is not a row is named
rather than silently rendered as one. Without that rule, the four lines of
letterhead of an emailed invoice come back as four rows with three empty cells,
and a caller iterating over `rows[1:]` reads a street address as a part number.
"""

from __future__ import annotations

import io

# Two words are on the same line if their baselines are within this many
# points. A ten-point font makes a line about twelve points tall, so three is
# generous without merging neighbouring rows.
SAME_LINE = 3.0

# Two words belong to the same cell when the gap between them is no wider than
# this. A space in a ten-point font is under three points; the gap between two
# columns of a table is tens of points. Ten sits between the two.
SAME_CELL = 10.0

# Two cells are in the same column when their left edges are within this.
SAME_COLUMN = 12.0

# In a guessed reading, a line with fewer filled cells than this is not a row
# of the table: it is the letterhead, the invoice number, a page footer, a
# paragraph of prose, or the second half of a designation that wrapped. All of
# them go to `dropped_lines`, with their text.
MIN_FILLED_CELLS = 2


def read_tables(pdf_bytes, *, pages=None) -> dict:
    """
    Every table of the document, page by page, with the reading that found it.

    `pages` is the list of page numbers to look at, counted from one; left out,
    every page is read.
    """
    try:
        import pdfplumber

        document = pdfplumber.open(io.BytesIO(pdf_bytes))
    except Exception as error:  # noqa: BLE001 - a broken file is an answer too
        return {"tables": [], "reason": f"this file could not be opened as a PDF: {error}"}

    found = []
    with document:
        for number, page in enumerate(document.pages, start=1):
            if pages is not None and number not in pages:
                continue
            ruled = page.extract_tables()
            if ruled:
                found.extend({"page": number, "strategy": "lines", "rows": rows,
                              "dropped_lines": []}
                             for rows in ruled)
                continue
            words = [{"text": w["text"], "x": w["x0"], "end": w["x1"], "y": -w["top"]}
                     for w in page.extract_words()]
            rows = group_into_rows(words)
            kept = [row for row in rows if _filled(row) >= MIN_FILLED_CELLS]
            dropped = [" ".join(c for c in row if c)
                       for row in rows if _filled(row) < MIN_FILLED_CELLS]
            if kept:
                found.append({"page": number, "strategy": "text", "rows": kept,
                              "dropped_lines": dropped})
    return {"tables": found, "reason": None}


def _filled(row) -> int:
    """How many cells of this line carry text."""
    return sum(1 for cell in row if cell)


def group_into_rows(words) -> list:
    """
    Words with coordinates, turned into a grid.

    Lines first, by baseline; then the columns, taken from the left edges seen
    across the whole page. A word is never cut: it belongs to the column its
    left edge is nearest, which is what keeps « Prix HT » whole.
    """
    if not words:
        return []

    # Lines, by baseline.
    lines = []
    for word in sorted(words, key=lambda w: (-w["y"], w["x"])):
        if lines and abs(lines[-1][0]["y"] - word["y"]) <= SAME_LINE:
            lines[-1].append(word)
        else:
            lines.append([word])

    # Cells, by the gap between words: « Moulin a cafe » is one cell, and the
    # eighty points that follow it are a column boundary.
    celled = []
    for line in lines:
        cells = []
        for word in line:
            if cells and word["x"] - cells[-1]["end"] <= SAME_CELL:
                cells[-1] = {"text": f"{cells[-1]['text']} {word['text']}",
                             "x": cells[-1]["x"], "end": word["end"]}
            else:
                cells.append(dict(word))
        celled.append(cells)

    # Columns, from the left edges seen across the whole page.
    columns = []
    for x in sorted(cell["x"] for line in celled for cell in line):
        if not columns or x - columns[-1] > SAME_COLUMN:
            columns.append(x)

    grid = []
    for line in celled:
        row = [""] * len(columns)
        for cell in line:
            index = min(range(len(columns)), key=lambda i: abs(columns[i] - cell["x"]))
            row[index] = f"{row[index]} {cell['text']}".strip()
        grid.append(row)
    return grid

/**
 * Read the tables of a PDF, and say how they were read.
 *
 * Rung N0. A table in a PDF is not a table: it is text placed at coordinates,
 * sometimes with lines drawn around it. Two readings follow from that, and
 * they are not equally trustworthy.
 *
 * When the table is ruled, the lines say where the cells are, and reading it
 * is exact. That is what `pdfplumber` does on the Python side of this entry,
 * and there is no equivalent of it in JavaScript: no package reads the rules
 * of a PDF and pairs them into a grid. So this file does the other reading
 * only, the one that guesses the columns from where the words sit, and
 * `strategy` says so on every table it returns.
 *
 * The consequence is measured in the test, and it is the reason this entry
 * reports the strategy at all: on a ruled table whose designation wraps onto
 * two lines, the Python extract returns three rows with the two lines in one
 * cell, and this one returns four with the second line alone.
 *
 * The grouping below is the same code in both languages, so that on a table
 * with no rules — the common case in an emailed invoice — the two answer
 * exactly the same thing.
 *
 * That guess is made from the whole page, not from the table: the columns come
 * from every left edge seen on the page, address block and footer included.
 * That is why the reading keeps only the lines with at least two filled cells
 * — « SARL Le Moulin » alone on its line is the letterhead, not a row. What it
 * left out is not thrown away: `dropped_lines` holds the text of every line it
 * refused, so nothing read on the page is lost, and what is not a row is named
 * rather than silently rendered as one. Without that rule, the four lines of
 * letterhead of an emailed invoice come back as four rows with three empty
 * cells, and a caller iterating over `rows.slice(1)` reads a street address as
 * a part number.
 */

// Two words are on the same line if their baselines are within this many
// points. A ten-point font makes a line about twelve points tall, so three is
// generous without merging neighbouring rows.
export const SAME_LINE = 3.0;

// Two words belong to the same cell when the gap between them is no wider than
// this. A space in a ten-point font is under three points; the gap between two
// columns of a table is tens of points. Ten sits between the two.
export const SAME_CELL = 10.0;

// Two cells are in the same column when their left edges are within this.
export const SAME_COLUMN = 12.0;

// A line with fewer filled cells than this is not a row of the table: it is
// the letterhead, the invoice number, a page footer, a paragraph of prose, or
// the second half of a designation that wrapped. All of them go to
// `dropped_lines`, with their text.
export const MIN_FILLED_CELLS = 2;

/** How many cells of this line carry text. */
const filled = (row) => row.filter((cell) => cell).length;

/**
 * Every table of the document, page by page, with the reading that found it.
 *
 * `pages` is the list of page numbers to look at, counted from one; left out,
 * every page is read.
 *
 * @param {Uint8Array} pdfBytes
 * @param {{pages?: number[], load?: object}} [options]
 */
export async function readTables(pdfBytes, { pages, load } = {}) {
  const pdfjs = load ?? (await import('pdfjs-dist/legacy/build/pdf.mjs'));
  const found = [];
  try {
    const document = await pdfjs.getDocument({
      data: new Uint8Array(pdfBytes), isEvalSupported: false,
    }).promise;
    for (let number = 1; number <= document.numPages; number += 1) {
      if (pages && !pages.includes(number)) continue;
      // eslint-disable-next-line no-await-in-loop -- pdf.js hands pages out one at a time
      const content = await (await document.getPage(number)).getTextContent();
      const words = content.items
        .filter((item) => (item.str ?? '').trim())
        .map((item) => ({
          text: item.str.trim(),
          x: item.transform[4],
          end: item.transform[4] + item.width,
          y: item.transform[5],
        }));
      const rows = groupIntoRows(words);
      const kept = rows.filter((row) => filled(row) >= MIN_FILLED_CELLS);
      const dropped = rows.filter((row) => filled(row) < MIN_FILLED_CELLS)
        .map((row) => row.filter((cell) => cell).join(' '));
      if (kept.length > 0) {
        found.push({ page: number, strategy: 'text', rows: kept, dropped_lines: dropped });
      }
    }
  } catch (error) {
    return { tables: [], reason: `this file could not be opened as a PDF: ${error.message}` };
  }
  return { tables: found, reason: null };
}

/**
 * Words with coordinates, turned into a grid.
 *
 * Lines first, by baseline; then the cells, by the gap between words; then the
 * columns, taken from the left edges seen across the whole page. A word is
 * never cut: it belongs to the column its left edge is nearest.
 */
export function groupIntoRows(words) {
  if (words.length === 0) return [];

  // Lines, by baseline.
  const lines = [];
  for (const word of [...words].sort((a, b) => b.y - a.y || a.x - b.x)) {
    const last = lines.at(-1);
    if (last && Math.abs(last[0].y - word.y) <= SAME_LINE) last.push(word);
    else lines.push([word]);
  }

  // Cells, by the gap between words: « Moulin a cafe » is one cell, and the
  // eighty points that follow it are a column boundary.
  const celled = lines.map((line) => {
    const cells = [];
    for (const word of line) {
      const last = cells.at(-1);
      if (last && word.x - last.end <= SAME_CELL) {
        last.text = `${last.text} ${word.text}`;
        last.end = word.end;
      } else {
        cells.push({ ...word });
      }
    }
    return cells;
  });

  // Columns, from the left edges seen across the whole page.
  const columns = [];
  for (const x of celled.flat().map((cell) => cell.x).sort((a, b) => a - b)) {
    if (columns.length === 0 || x - columns.at(-1) > SAME_COLUMN) columns.push(x);
  }

  return celled.map((line) => {
    const row = Array(columns.length).fill('');
    for (const cell of line) {
      let index = 0;
      for (let i = 1; i < columns.length; i += 1) {
        if (Math.abs(columns[i] - cell.x) < Math.abs(columns[index] - cell.x)) index = i;
      }
      row[index] = `${row[index]} ${cell.text}`.trim();
    }
    return row;
  });
}
